- On-top scan design protects fragile plant specimen
- 1,600-dpi color CCD provides high-resolution image
- Adjustable scan beds are convenient for objects beyond focus
- Up to +/- 6.5 mm DOF can get clear extended DOF images
- Automated metadata recognition ability
- Image archive and privileged account management system

To significantly solve digitization inefficiency common to the global herbaria museums, Microtek launches a workstation consisting of ObjectScan 1600 scanner, ScanWizard_Botany software, and MiVapp_Botany archive management system. This integrated workstation is characterized by, (1) On-top scan design for full-frame focus, (2) 1600 dpi (equal to 1 Gigabyte pixels) color CCD, (3) Optical Character Recognition (OCR) for specimen label and 1D barcode, and (4) image archive and privileged-account cloud management system. Both software and management system provide intuitive interface for non-IT herbarium curators and botanists, especially for herbarium inexperienced volunteers. The database structure follows JSTOR principle in order for the file exchange convenience between herbaria. Further, MiVapp_Botany can unit global academic efforts to speed up verification rate on image quality and metadata by offering remote log-in entry service. Under ideal set-up, this workstation can digitize 500,000 – 800,000 specimen per year where cost will be less than 5 USD for each specimen.

NO.	Item	Details
01	Product Name	ObjectScan 1600
02	Scanner Type	On-top Scan Flatbed Scanner
03	Image Sensor Type	Color Linear CCD
04	Resolution	1600 dpi
05	Light Source	LED
06	Scanning Area	304.8 mm x 424.18 mm (12" × 16.7")
07	Scanning Speed	12 sec @ 400 dpi, A3 Color (without calibration)
08	Bit Depth	48-bit (Input) / 24-bit (Output)
09	Connectivity	Hi-Speed USB 2.0
10	Supported File Types	TIFF, JPEG, BMP, PDF
11	OS Support	Windows 7 / 8
12	Dimensions (L x W x H)	750 x 470 x 376 mm / 29.5" x 18.5" x 14.8" (foot stands excluded)
13	Weight	47 kg (103 lbs)
14	Power Source	AC 100V-240V, 47-63 Hz, 1.5A max. (Input) DC 15V, 2.5A (Output)
15	Power Consumption	37.5 W
16	System Requirements PC	CD-ROM drive (for installing software) Color display with 24-bit color output capability 4 GB RAM or more Intel Core i5 Processor at 3.0 GHz PC or higher with Hi-speed USB (USB 2.0) port Microsoft Windows 7 / 8
17	Software Included	ScanWizard Graph
PS : Product specifications described herein are subject to change without notice.

Warranty

This product is sourced in Australia and carries a full Australian Manufacturers Warranty

Brochure
